Wall-mounted air conditioner CEBU S2

mono-splitresidentialcommercial

Product overview
Single split air conditioner connecting one outdoor unit to one indoor unit for targeted cooling or heating of a single room or one-zone area. Suitable for spaces such as bedrooms, home offices or small commercial rooms. The Cebu S2 range enables combinations of outdoor and indoor units to meet installation requirements.

Model and variants
Model code: AR50F07C1AHNEU
Available capacity on this page: 2.0 kW. Other capacities in the Cebu S2 range: 2.5 kW, 3.5 kW, 4.2 kW, 5.2 kW and 6.8 kW.
Power supply: 1 Phase (220-240 V, 50 Hz).

Key features

• Auto Clean — Dries the heat exchanger after shutdown using a three-step process to reduce bacteria and odours. Can be enabled or disabled via the remote.
• 4-Way Swing — Automatic up/down and left/right swing for even air distribution and to avoid direct drafts.
• Easy Filter Plus — Top-located external filter removable and cleanable without opening a cover; dense mesh and protective coating capture dust and limit some airborne contaminants.
• Smart Control / SmartThings — Wi‑Fi embedded for remote operation, scheduling and power monitoring via the SmartThings app (requires Wi‑Fi and SmartThings account).
• SolarCell Remote Controller — Solar-powered remote included; reduces battery use and supports USB‑C charging.

Other functionality

• WindFree Cooling: No (this indoor unit)
• Tri-Care Filter: No
• Auto Clean (Self Cleaning): Yes
• Fast Cooling, Eco modes, Dehumidification, Quiet mode, Good Sleep, Auto Changeover, Auto Restart: Yes

Energy & performance summary
SEER: 7.60 W/W
EER (Cooling): 4.35 W/W
COP (Heating): 4.68 W/W
Energy class (cooling): A++
Energy class (heating, average season): A+

Documentation
Declaration of Conformity available as product documentation.

Technical specifications

• Capacity (Cooling): 2.00 kW (6,824 Btu/hr)
• Capacity (Heating): 2.20 kW (7,506 Btu/hr)
• Capacity (Cooling, Min - Max): 1.05 ~ 3.0 kW (3,583 ~ 10,236 Btu/hr)
• Capacity (Heating, Min - Max): 0.85 ~ 4.5 kW (2,900 ~ 15,355 Btu/hr)
• SEER: 7.60 W/W
• EER (Cooling): 4.35 W/W (14.84 Btu/hW)
• COP (Heating): 4.68 W/W (15.97 Btu/hW)
• Energy efficiency class (cooling): A++
• Energy efficiency class (heating): A+
• Sound power level (Indoor, Cooling): 54 dBA
• Sound power level (Outdoor, Cooling): 60 dBA
• Noise level Indoor (High / Low): 37 / 19 dBA
• Noise level Outdoor (High/Low): 45 dBA
• Power source: 1 / 220-240 V / 50 Hz
• Power consumption (Cooling): 460 W
• Power consumption (Heating): 470 W
• Operating current (Cooling): 2.4 A; (Heating): 2.5 A
• Gross dimension (Indoor, W x H x D): 880 x 290 x 375 mm
• Gross dimension (Outdoor, W x H x D): 834 x 620 x 323 mm
• Net dimension (Indoor, W x H x D): 820 x 299 x 215 mm
• Net dimension (Outdoor, W x H x D): 710 x 540 x 220 mm
• Gross weight (Indoor): 11.0 kg; Gross weight (Outdoor): 26.2 kg
• Net weight (Indoor): 9.1 kg; Net weight (Outdoor): 24.0 kg
• Loading quantity (20/40/40Hft without Pipe): 105 / 215 / 252
• Maximum piping length: 15 m
• Maximum piping height: 8 m
• SVC valve sizes: Liquid 6.35 mm; Gas 9.52 mm
• Moisture removal: 0.7 l/hr
• Air circulation (Cooling): 9.5 m3/min
• Refrigerant type: R32 (GWP = 675)
• Refrigerant charge: 0.70 kg (0.47 tCO2e)
• Operating ambient (Cooling): -10 ~ 46 °C
• Operating ambient (Heating): -15 ~ 24 °C
• Outdoor unit compressor type: BLDC
• Outdoor unit anti-corrosion fin: Yes
• Air direction control: Auto (Up/Down and Left/Right)
• Air flow control steps (Cool/Fan): 5 / 4
• Air purification notes: PM1.0 filter: No; Tri-Care Filter: No; Easy Filter Plus (Anti-Bacteria) for this variant: No; Auto Clean: Yes
• Convenience & smart features: WiFi embedded: Yes; SmartThings support: Yes; AI Auto Cooling: Yes; Motion Detect Sensor: No; Filter cleaning indicator: Yes; Indoor temperature display: Yes; Display On/Off: Yes; Beep On/Off: Yes; 24-hour timer: Yes; Auto Restart: Yes
