Powerful, robust and reliable powertrain & hydraulic components for long life in the most demanding applications. Selectable working modes match machine performance to the application, maximizing productivity
Optimized positive flow hydraulics improve operating efficiency by up to 5% and fuel efficiency by up to 10%
Engine Model CUmmins QSL9
Engine Displacement 8.9L
Fuel Tank 540L
Radiator 36L
Hydraulic Tank 300L
Bucket Digging Force 204KN
Arm Digging Force 153KN
Carrier Wheel on Each Side 2
Thrust Wheel on Each Side 8
Standard Boom 6.15m
Standard Stick 3.2m
Bucket Capacity 1.7m³
