Weight indicator system
GPS fleet management system
Horizontally move function
Reliable boom and steel structure, pass strict test
74 HP for option, no DEF tank, simple and reliable
Spacious service room,easy to access
Key component using American local brand
Engine Model DEUTZ TD2.9 55kW
Rated Power 55/2300Kw/rpm
Gearbox DANA 1104FVDT12366
Axle DANA 212
Rated Capacity 2.72T
Overall Weight 7.2T
Max Lifting Height 10.4m
Max Travelling Speed 28km/h
Min. Turning Radius 4.2m
Wheel Base 3.14m
