When system pressure reaches 12Mpa:No. of stroke reaches 29t/Min. Pump efficiency increases 25%(Max). Diesel consumption decreases 10%.
To use top rotation brake technology to control the amplitude of Boom on swing, the boom's overswing amplitude is reduced by 60%.
Delivery pipe
Discharge port/transition bushing
Concrete piston
Wear plate/cutting ring
Delivery cylinder
Continually monitors more than 200 aspects of the system during operation. Faults are displayed on the monitor. Review of the detected faults can reduce troubleshooting time by 70%.
Overload protection for boom cylinders
Agitator safety switch off
Boom interference preventing technology
Length 10690mm
Width 2500mm
Height 3760mm
Empty Weight 18000kg
Vertical Reach 30.1m
Horizontal Reach 26.5m
Reach Depth 15.2m
Output 101m³/h
Pressure 6MPa
Chassis Brand SANY
Chassis Model SYM1180T1E
