Concrete ventilation grill P Series
rectangularsquareexterior

concrete ventilation grill
concrete ventilation grill
concrete ventilation grill
concrete ventilation grill
concrete ventilation grill
concrete ventilation grill
concrete ventilation grill
Add to favorites
Compare this product


Characteristics

Material
concrete
Shape
rectangular, square
Interior/exterior use
exterior
Applications
for facade
Market
industrial
Width

20 cm, 25 cm, 40 cm, 50 cm, 60 cm (8 in)

Length

40 cm, 50 cm, 60 cm (16 in)

Description

Thin-slatted Louvres are a traditional system of ventilation. Being entirely manufactured in concrete, they require no maintenance and are fully weatherproof. These louvres solve the need for continuous ventilation especially in industrial settings such as drying sheds, power sheds, and markets; and for housing storage rooms, garages, burner rooms, lift machinery rooms, wine cellars and other service areas. P-20 Dimensions (cm) A x B 20 x 40 Espacio libre entre lamas 3.00 Superficie ventil. cm² 190.00 Piece Weight (kg) 6,1 Pieces Palet 144 Weight Palet (Kg) 893 P-25 Dimensions (cm) A x B 25 x 50 Espacio libre entre lamas 4.00 Superficie ventil. cm² 340.00 Piece Weight (kg) 9,5 Pieces Palet 76 Weight Palet (Kg) 738 P-40 Dimensions (cm) A x B 40 x 40 Espacio libre entre lamas 7.00 Superficie ventil. cm² 586.00 Piece Weight (kg) 11,1 Pieces Palet 48 Weight Palet (Kg) 548 P-50 Dimensions (cm) A x B 50 x 50 Espacio libre entre lamas 8.00 Superficie ventil. cm² 884.00 Piece Weight (kg) 16,8 Pieces Palet 38 Weight Palet (Kg) 655 P-60 Dimensions (cm) A x B 60 x 60 Espacio libre entre lamas 9.00 Superficie ventil. cm² 1.41 Piece Weight (kg) 22,7 Pieces Palet 32 Weight Palet (Kg) 741
