Hanging light fixture PALADIO LENSsurface mountedrecessed ceilingLED
Add to favorites
Compare this product
Characteristics
- Type
- hanging, surface mounted, recessed ceiling
- Light source
- LED
- Shape
- linear
- Protection class
- IP20
- Application
- commercial
- Material
- aluminum profile
- Color
- black, silver-colored, gold-colored, bronze look
- Style
- contemporary
- Dimmable
- dimmable
- Number of lights
- single, multiple, double
- Other characteristics
- DALI, modular lighting system, indirect
- Height
70 mm
(3 in)- Length
Max.: 3,930 mm
(155 in)Min.: 1,130 mm
(44 in)- Width
35 mm
(1 in)- Luminous flux
Max.: 5,620 lm
Min.: 1,240 lm
- Color temperature
Max.: 6,500 K
Min.: 2,700 K
2,700 K, 3,000 K, 4,000 K
Description
Luminaires of the PALADIO LENS series have highly efficient miniature lens reflectors, UGR < 19.
This innovative system combines the advantages of lenses and reflectors, with the recessed lens taking over the task of luminous flux distribution, while the reflector reliably reduces the resulting lateral glare.
Due to these extremely low glare values, the luminaire complies with the EN 12464-1 standard. By default, the lenses have a beam angle of 60°.
35 mm wide aluminium profile with high-quality brushed and anodised surface in different colours. Pendant, surface mounted and recessed mounted versions are available. Can be used as an individual single luminaire or system luminaire with PALADIO CONNECT elements
