Folding-arm awning MARKISOLETTE 120, 103

manual

Markisolette 120 is a system that combines features of both awning and roller blind. The new square cassette provides modern design and improved aesthetics. Depending on the installation characteristics, the following guide rails can be used: GC30, GC30F, and GC30FD. Properties: • Cassette dedicated for concealed installation made of aluminium sheet. The cassette has an extension that enables putting plaster on it. • Cassette dedicated for niche and facade installation made of extruded aluminium. • Extruded aluminium sideguides • Special arm ranging from 90-135 degress • Self-supporting option available • Revision from the bottom of the cassette • Wide range of fabrics • Electrical drive • Construction available in any color from RAL palette colour palette: RAL electric drive: yes manual drive: no maximum width: 3.5 m maximum projection: 4.0 m external application: yes internal application: no
