Self-propelled cold planer SMT200M-C7

largefor asphaltfor concrete

Overview
Cold milling machine designed for removal of asphalt and concrete pavements for road maintenance and resurfacing. Provides high power and stable operation for heavy milling tasks up to 330 mm depth.

Key features

• High-efficiency construction: 563 kW electronically-controlled injection engine (Cummins QSM15 77C, Tier 3) and 30,500 kg operating weight ensure stable performance; large-swing-angle conveyor belt increases material-receiving range.
• Fuel economy and durability: Rear-mounted dual-fan temperature-controlled cooling improves fuel efficiency; water system with clogging alarm extends cutter life; compact hydraulic oil tank reduces maintenance costs.
• Operator comfort and maintainability: Quick-change cutter holder system reduces cutter head and holder disassembly time by about 50%; standard rear-view camera enhances safety; shock-absorbing power and transmission systems reduce vibration; blow-type cooling keeps air ducts away from operator console for a more comfortable environment.

Technical specifications

• Model: SMT200M-C7
• Engine power (kW/rpm): 563/2100
• Operating weight (kg): 30500
• Maximum milling width (mm): 2000
• External dimensions (mm): 15350×2800×3930
• Engine model: Cummins QSM15 77C (Tier 3)
• Maximum milling depth (mm): 330
• Number of milling tools: 148
• Milling diameter including tools (mm): 1020
• Conveyor belt width (mm): 850
• Operating speed (m/min): 0-100
• Travel speed (km/h): 0-6
• Emissions: Tier 3 (as per China standards)

Applications

• Road rehabilitation and expressway maintenance projects, including pavement removal prior to resurfacing (see product page for case images and references).

Ordering and support

• Available options include cutter types and conveyor configurations. Contact the supplier for spare parts, service packages and local support.
