FLUSHOMETER FEATURES
Locking Vandal Resistant Stop Cap
Adjustable Tailpiece
High Back Pressure Vacuum Breaker Flush Connection with Onepiece Bottom Hex Coupling Nut
Sweat Solder Adapter with Cover Tube and Cast Set Screw Wall Flange
Non-Hold-Open Handle, Fixed Metering Bypass and No External
Volume Adjustment to Ensure Water Conservation
Handle Packing, Main Seat, Stop Seat and Vacuum Breaker molded from PERMEX Rubber Compound for Chloramine Resistance
1” I.P.S. Screwdriver Bak-Chek® Angle Stop
Valve designed to accept Low and Ultra-Low Consumption Pistons only to ensure Water Conservation
ADA Compliant Metal Oscillating Non-Hold-Open Handle
FIXTURE FEATURES
White Vitreous China
Elongated bowl
Floor mounted, floor outlet
Siphon jet flushing action achieves 1000g Map score when used with any Sloan flushometer
Water spot area: 10⅛" x 9⅜" (26 cm x 24 cm)
1½" I.P.S. top spud inlet
2⅛" fully glazed trapway
Closet bolts and caps included
Toilet seat not included
Static load rating of 1000 lbs. (See Notes)
