Road sign pole 40H

steelABScustomizable

Overview
Main support pole designed for mounting payment terminals and peripheral hardware on tabletops. Diameter 38 mm and height 40 mm. Compatible with SNS series terminals and peripherals; suitable for fixed installation using the supplied screw kit or optional 3M adhesive.

Product details

• Product code: SNS-L#40
• Diameter: 38 mm
• Height: 40 mm
• Base circumference: 98 mm
• Available colors: Black, White (customizable via RAL code)
• Materials: FE360 steel (structural components), ABS plastic (covers/finishing)

Technical specifications

• Screw standards: 4 x ISO 7380 M8*60
• Locking nuts: 4 x ISO 7040 M8 self-locking nuts
• Tool included: 1 x DIN911 SW4 hex key
• Mounting options: screw kit for tabletop installation or 3M adhesive
• Base cover supplied

Mounting & installation

• Install on flat tabletops using the supplied screw kit (verify tabletop thickness before installation)
• Alternative: secure base with industrial 3M adhesive for non-penetrative mounting
• Ensure alignment and torque per component manufacturer recommendations

Compatibility & security

• Compatible series: SNS#PINPAD, SNS#PRINTER, SNS#B1
• Kensington hole integrated for use with dedicated anti-snatch locks

Included accessories & packaging

• 4 x ISO 7380 M8*60 screws
• 4 x ISO 7040 M8 self-locking nuts
• 1 x DIN911 SW4 hex key
• Base cover
