Audio inputs with CINCH connectors.
Internal Mono/Stereo switch.
Built-in 60 VA supply source, supplying 16 V DC with electronic fi lter for general supply of
the system.
Mains input voltage: 230V AC (50/60 Hz) P3271, 115V AC (50/60 Hz) P3272.
Electronic protection against short-circuits and overloads in the supply.
Telecontrol. When any of the system controls are activated, socket automatically connects
supplying 220V to the sound source. When all the controls of the system are switched off
this socket disconnects automatically, switching off the sound source, with the subsequent
energy saving.
Local control. To switch on the outer sound source manually, regardless of the state of the
system controls.
Two-pin power switch to totally disconnect the system. LED indicating operation of the
unit.
All the components used for connection to the mains are officially approved, complying
with the strictest safety regulations.
Internal fan with automatic activation.
Music channels: 1
Power: 60 VA
Sound Output Level: 3 V RMS
Maximum Current 4 A
Frequency Response: 10Hz. - 25KHz. (-3dB)
Signal/Noise Ratio: > 70 dB
Input Impedance: 10K Ohm
Maximum Sensitivity: 60 mV
Recommended Input Level: 100mV - 2V
(máx. 25V)
Mains Input: 230 V AC 50/60 Hz
V Output Adjusted Between: regulada entre
16 V y 13 V DC
Dimensions: 142 x 146 x 50 mm
Weight: 480
