Modern wall light BRIGG ADJUSToutdoorcylindricalorientable
Add to favorites
Compare this product
Characteristics
- Style
- modern
- Interior/exterior use
- outdoor
- Diffuser shape
- cylindrical
- Type of support
- orientable, adjustable
- Applications
- for hotel, for exhibitions, for public building
- Light source
- LED
- Number of lights
- 2 bulb
- Color
- black, silver-colored, white
- Dimmable
- dimmable
- Designer
- not specified
- Other characteristics
- dimmable, with wireless control
- Height
Max.: 60 mm
(2 in)Min.: 60 mm
(2 in)- Length
Max.: 300 mm
(12 in)Min.: 300 mm
(12 in)- Luminous flux
Max.: 3,000 lm
Min.: 2,400 lm
- Color temperature
Max.: 6,000 K
Min.: 2,700 K
- Color rendering index (CRI)
Max.: 100 unit
Min.: 90 unit
Description
Product name
LONG BRIGG ADJUST
Design
Design: Andreas Steng
Overview
BRIGG ADJUST expands the classic BRIGG family of wall luminaires to provide maximum flexibility. Two independently pivoting light sources allow precise beam aiming and versatile wall accenting. Can be mounted as uplight or downlight; optional separate control of both sources enables advanced lighting schemes. Available in multiple CCTs with CRI 90+ and standard dimming options.
Photometric features
Housing finishes
Dimming options
Beam distribution
Two independently adjustable spots with beam angles 12°, 24° or 36°. Possibility for symmetric or asymmetric distribution and additional uplight/downlight depending on mounting orientation.
Data / Downloads
Datasheet: LONG BRIGG ADJUST datasheet (product data available as a datasheet).
Recommended applications
Suitable for projects requiring flexible wall accenting and architectural wall lighting; adaptable to corridors, galleries, facades and reception areas.
Technical specifications
LONG BRIGG ADJUST
Design
Design: Andreas Steng
Overview
BRIGG ADJUST expands the classic BRIGG family of wall luminaires to provide maximum flexibility. Two independently pivoting light sources allow precise beam aiming and versatile wall accenting. Can be mounted as uplight or downlight; optional separate control of both sources enables advanced lighting schemes. Available in multiple CCTs with CRI 90+ and standard dimming options.
Photometric features
- Output ranges: 2,400 - 3,000 lm
- Correlated color temperatures: 2700K, 3000K, 4000K, 5000K, 6000K
- Color rendering: CRI 90+
Housing finishes
- White textured RAL 9016
- Black textured RAL 9005
- Alu textured RAL 9007
- Special RAL colours on request
Dimming options
- Phase-cut (leading/trailing edge)
- 1–10 V
- DALI
- CASAMBI
Beam distribution
Two independently adjustable spots with beam angles 12°, 24° or 36°. Possibility for symmetric or asymmetric distribution and additional uplight/downlight depending on mounting orientation.
Data / Downloads
Datasheet: LONG BRIGG ADJUST datasheet (product data available as a datasheet).
Recommended applications
Suitable for projects requiring flexible wall accenting and architectural wall lighting; adaptable to corridors, galleries, facades and reception areas.
Technical specifications
- Model: BRIGG ADJUST (LONG version)
- Dimensions: W 300 x D 200 x H 60 mm
- Output ranges: 2,400 - 3,000 lm
- Correlated color temperatures: 2700K / 3000K / 4000K / 5000K / 6000K
- CRI: 90+
- Housing finishes: RAL 9016, RAL 9005, RAL 9007, special RAL colours on request
- Dimming options: Phase-cut (leading/trailing edge), 1–10 V, DALI, CASAMBI
- Spot beam angles: 12°, 24°, 36°
- Mounting: Up- or downlight; separate control of light sources possible
