Wall-mounted scooter rack SCOOTY

for schoolfor public spacefor playground

Product description
SCOOTY is a practical stand designed specifically for collective parking of scooters. With a simple yet sturdy construction, it accommodates up to five scooters per unit. Stands can be connected using a joining link to form continuous rows. It is suitable for sites where scooters are a common transport option for children and adults — schoolyards, playgrounds, daycare parking zones, cultural centres and community parks.

Design
Jan Padrnos

Construction and anchoring
Galvanized steel load-bearing structure with powder-coat finish. The top section with cut-outs is made from a compact board. Anchoring is via threaded rods into pre-cast concrete foundations or into a wall. Stands can be linked with a connecting element to create continuous rows.

Models
SSC1 — D×W×H: 1235×497×596 mm / 13 kg — floor-anchored stand / for 5 scooters
SSC2 — D×W×H: 1235×481×325 mm / 11 kg — wall-mounted stand / for 5 scooters

Advantages

• Capacity: allows parking of up to five scooters simultaneously.
• Anchoring options: choice of floor or wall mounting.
• Compact footprint: dimensions allow installation in tight spaces.

Finish and available colours / materials
Galvanized metal structure with powder-coat finish. Top plate made from compact boards with cut-outs.

• Available surface shades (RAL and Corten): RAL 1001, RAL 1021, RAL 1033, RAL 2008, RAL 3003, RAL 5024, RAL 6010, RAL 6021, RAL 6034, RAL 7006, RAL 7016, RAL 9003, RAL 9005, RAL 9006, RAL 9007, Corten tone.
• Compact board types (codes): B070, C017, C190, M102, P001, R057.

Technical specifications

• Product name: SCOOTY
• Designer: Jan Padrnos
• Models: SSC1 (floor anchoring), SSC2 (wall-mounted)
• Capacity: 5 scooters per unit
• Dimensions SSC1 (D×W×H): 1235×497×596 mm
• Weight SSC1: 13 kg
• Dimensions SSC2 (D×W×H): 1235×481×325 mm
• Weight SSC2: 11 kg
• Structure material: galvanized steel
• Surface treatment: powder-coat finish
• Anchoring: threaded rods into pre-cast concrete foundations or into a wall
• Connectability: yes, via connecting link for longer rows
• Available colours: see RAL list above
• Available top plate types: B070, C017, C190, M102, P001, R057
