Active chilled beam PACIFIC

Integrated climate beam with cooling, heating and ventilation The PACIFIC is a high-performance climate beam for installation in false ceilings. With high built-in flexibility, it is designed to meet today’s needs as well as those of tomorrow. The modular design offers great freedom of choice for configuring its arrangement to meet current needs. Supply air, cooling and heating Supply air, cooling and electric heating Additional module SA/EA with extra supply air (SA) and additional extract air (EA) in the same face plate as PACIFIC. One product in the ceiling - five different functions! Behind the PACIFIC face plate, the SA/EA version has an extra module for supply air (SA) and/or extract air (EA). Together with cooling, heating and primary air supply this give an exceptional 5-in-1 product. The features save money through lower investment costs and easy installation — and provide an attractive solution with the same design for several functions! PACIFIC SA/EA air flow demonstration: PACIFIC - - - Primary air flow: - Up to 75 l/s - - Pressure range: - 30 to 150 Pa - - Cooling capacity: - Up to 3400 W - - Heating capacity: Water: Up to 3500 W - Electric: Up to 1000 W - Length: - 1200 / 1800 / 2400 / 3000 mm* - - Width: - min. 594 mm / max. 667 mm* - - Height:-163 mm – Ø100 mm air connection-189 mm – Ø125 mm air connection - 277 mm – Ø160 mm air connection The PACIFIC is obtainable in lengths and widths that fit the majority of false ceilings available on the market. Additional module SA/EA - - Supply air flow SA: - Up to 65 l/s - - Cooling capacity SA: - Up to 470 W - - Extract air flow EA: - Max 100 l/s
