Commercial air handling unit R5 SMART

homecompact

Compact air handling unit with high performance Residential air handling unit with rotary heat exchanger (598 x 600 x 597 mm, Ø160 mm) with modular dimensions for installation in the bathroom or laundry room in houses and large apartments (432 m³/h, 240 m²). Equipped with a fifth duct connection for the possibility to connect an external cooker hood. The market’s most intelligent demand-controlled humidity function as standard. Developed, manufactured and tested for Nordic climate. Ecodesign energy class A* Air flow range 126 - 432 m³/h Temperature efficiency up to 86 % (EN 308) Annual efficiency up to 81 % (Stockholm 21°C) Demand-controlled humidity function as standard Automatic summer function and passive cooling Anti-frost protection ensures continuous ventilation External coils for heating and cooling as an option Can be connect to the automated building management system (I/O / Modbus) Mounted on the wall or ceiling. Control System CASA Smart Controls (options) CASA Smart ventilation units are equipped with the market’s most versatile control options! Select the required control method or combine several! Smart control panel Smart Access for mobile connection CASA Smart cooker hoods (connected with a separate duct) Centralised building automation (with SEM Modbus module or configurable I/O). Swegon CASA R5 Smart Residential air handling unit with rotary heat exchanger (598 x 600 x 597 mm, Ø160 mm) with modular dimensions for installation in the bathroom or laundry room in houses and large apartments (432 m³/h, 240 m2). Equipped with a fi ft h duct connection for the possibility to connect an external cooker hood.
