Casement window SOLEAL 55 EVOLUTION
tilt-and-turnfixedtop-hung

casement window
casement window
casement window
casement window
casement window
casement window
casement window
casement window
casement window
Add to favorites
Compare this product


Characteristics

Opening system
casement, tilt-and-turn, fixed, top-hung
Material
aluminium
Glazing
double-glazed, triple-glazed
Performance
thermal break, acoustic
Technical characteristics
wind-proof, waterproof, high-performance
Other characteristics
for commercial buildings, residential
Height

145 cm, 148 cm, 160 cm, 225 cm (57.09 in)

Width

120 cm, 125 cm, 148 cm (47.24 in)

Description

SOLEAL 55 EVOLUTION MINIMAL OPENING FRAME The universal window performant at refined style. VISIBLE OPENING SASH The universal aluminium window to answer all styles. C2C Bronze certified product, a recognised label in favour of eco-design and circular economy.. 55 mm module and thermal break of 20 mm Minimizing the impact of the aluminium structure, perimetral frame of 52 mm et central rebate of 66 mm 3 stylistic lines Contemporary Classic Tradition Visible opening on the inside and outside Large choice of applications for a better adaptation to each project All these applications are available with concealed drainage. Compatible with sliding systems and doors from the same line. Product benefits LARGE SIZES Max dimensions up to W 1,2 m x H 2,25 m Max weight up to 130 kg Glass infill from 24 to 42 mm DIVERSITY OF APPLICATIONS Fixed Frame Bottom hung window Side hung window 1 & 2 leaves Tilt & turn / Turn & tilt window 1 & 2 leaves Composite frame Top hung window HIGH PERFORMANCE Uw up to W 1,2 W/m².K, TLw = 0,61 et Sw =0,50 with triple glazing (Ug = 0,6 + warm edge) - Patio door 1 leaf L 1,25 m x H 2,18 m 40 dB (Ra, Tr) for tilt and turn window 1 leaf HIGH PERFORMANCE Air permeability: Class 4 Water tightness: Class 9A Wind pressure resistance: Class C3 1 leaf tilt & turn window (W 1.40 m x H 1.60 m)

Catalogs

No catalogs are available for this product.

See all of TECHNAL‘s catalogs
