Air/water heat pump HYBREER 3

residentialfor outdoor installationfor indoor installation

HYBREER 3 is a hybrid system for space heating/cooling and DHW production. specifically designed to simplify the replacement of the boiler of existing air conditioning systems. Possibility to configure the D.H.W. production in external storage systems serving the heat pump and other renewable sources such as solar thermal. It consists of: air-water heat pump, hydraulic connection kit, combi condensing wall-hung boiler Air-water heat pump HP_OWER ONE 70R/90R/120R or HP_QOR 70/90/120 high efficiency FULL INVERTER, super compact for outdoor installation. KONm 24/35 condensing boiler, also with storage tank (KON B 28) or boiler XLD (long distance) HYBREER hydraulic connection kit • manifold / hydraulic compensator • insulation for hot / cold applications • non-return valves • mounting bracket • at sight installation with white painted sheet metal cover • embedded installation with dedicated box (optional) • booster circulator kit (optional) • relay kit for emergency boiler management in relation to the external temperature HYBREER 2 is a “hybridization” kit for an existing system served by a boiler. It consists of: air-water heat pump HP_OWER ONE R and hydraulic connection kit
