Flat roofing panel STRUCTO-CRETE®metal lookthermal
Add to favorites
Compare this product
Characteristics
- Type
- flat
- Appearance
- metal look
- Technical characteristics
- thermal
Description
STRUCTO-CRETE® Brand Structural Roof Deck Panels are cementitious, noncombustible concrete roof panels designed to provide structural roof sheathing and to serve as nail base or thermal barrier for roof systems. They are FM-approved, dimensionally stable, and intended for fast, dry installation without pouring, setting or curing.
Overview
A concrete roof deck that can be combined with other noncombustible materials to create 1- and 2-hour fire-rated roof-ceiling assemblies. The only cementitious structural panel approved by Factory Mutual (FM) — FM Approval Standard 4472. STRUCTO-CRETE® Roof Deck Panels can be applied with mechanical fasteners to serve as a structural substrate for adhesive-applied roof systems. ICC-ES Evaluation Report: ESR-1792.
Key features
Documentation & approvals
Technical specifications
Overview
A concrete roof deck that can be combined with other noncombustible materials to create 1- and 2-hour fire-rated roof-ceiling assemblies. The only cementitious structural panel approved by Factory Mutual (FM) — FM Approval Standard 4472. STRUCTO-CRETE® Roof Deck Panels can be applied with mechanical fasteners to serve as a structural substrate for adhesive-applied roof systems. ICC-ES Evaluation Report: ESR-1792.
Key features
- FM Approved (FM Approval Standard 4472)
- Durable, noncombustible cementitious concrete panel
- Dimensionally stable — will not buckle or warp like wood sheathing; resists moisture issues associated with poured concrete
- Exceptional uplift ratings and strong, durable construction
- Dry construction method — allows roof system application immediately after panel installation
- Can be installed up to 48 in. on center over cold-formed steel framing, 1/4 in. bar joists, or wood framing to create 1- and 2-hour fire-rated roof/ceiling assemblies
- Meets criteria of ASTM E136-16 for use in all types of noncombustible construction
- Made in the USA with domestic and imported materials
Documentation & approvals
- ICC-ES Evaluation Report: ESR-1792
- Factory Mutual (FM) approval per FM Approval Standard 4472
Technical specifications
- Panel Size: 48 in. x 4 - 8 ft.
- Thickness: 3/4 in.
- Edge: Square, V-Shaped Tongue and Groove
- Mold Resistance: Meets
- Moisture Resistance: Yes
- Fire Rating: Firecode®
- Intended use: Structural roof sheathing; can serve as nail base or thermal barrier and as structural substrate for adhesive-applied roof systems
- Installation: Mechanically fastened; installed up to 48 in. on center over specified framing
