Wall-mounted pergola S-LUXE

extruded aluminumfabric canopycustom

S-LUXE RETRACTABLE ALUMINUM ELECTRIC LEAN-TO PERGOLA MADE TO MEASURE - Max. projection 5000mm, - Max. width 4000mm, - Extruded aluminum structure, - Unlimited structure colors (choice of universal RAL), - Extrusion thickness: 1.5mm to 2.3mm (depending on profile), - Professional fabric Ferrari® Soltis w96 620gr/m² or Professional PVC fabric Sauleda® Technical from 650gr/m² to 830gr/m², - Tensioning system ensures a taut fabric when rolled up and unrolled, - Feet 110mm x 110mm, height 2500mm, - Posts up to 3300mm possible, - Floor mounting bracket, - Stainless steel screws, - Trunk wall mounting, - Wall profile height: 110mm, - Large-axis tubular Cherubini motorization, - Extruded aluminum winding tube, - Water run-off through support beam, - Inclination 10% - Calculation info: 10% = 10cm/m height difference, - Approximate weight for a 4m x 5m pergola +/- 190KG, - Wind rating: Class 6 UNE EN 16561, - European manufacture, - 10-year warranty, - Free delivery in mainland France, - Lead time 8 to 10 weeks, - Factory-direct prices.
