Solar energy storage system 12813
commercialbatteryLiFePO4

Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4 - image - 2
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4 - image - 3
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4 - image - 4
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4 - image - 5
Solar energy storage system - 12813 - V-TAC - commercial / battery / LiFePO4 - image - 6
Add to favorites
Compare this product
Go to the V-TAC website for more information

Characteristics

Applications
battery, solar, commercial
Battery type
LiFePO4
Other characteristics
outdoor
Energy capacity

261 kWh

Power

125 kW
(169.95 hp)

Description

Product overview
  • 261 kWh high-voltage (HV) battery set supplied by Oliter, intended for solar PV energy storage applications.
  • Liquid cooling thermal management and IP65-rated enclosure for protected outdoor or indoor use.
  • Includes or is compatible with a 125 kW inverter (brand: Deye) as indicated.


Technical specifications
  • Battery capacity: 261 kWh
  • System type: HV battery set
  • Cooling method: liquid cooling
  • Ingress protection: IP65
  • Inverter: 125 kW (brand: Deye)
  • Category: Solar PV systems / Solar PV sets


Applications
  • Commercial and industrial photovoltaic energy storage
  • Grid-tied storage for peak shaving and load management
  • Backup power and microgrid installations


Installation & maintenance
  • Installation by qualified electrical or solar professionals is required
  • Liquid cooling requires a sealed coolant circuit and regular inspections
  • IP65 enclosure suitable for outdoor or sheltered outdoor installations


Ordering & integration
  • Provide site voltage and system requirements when requesting a quote
  • Contact supplier for compatibility, available variants and integration details
Go to the V-TAC website for more information
