Electric chain hoist VHR HPR

Low headroom version manual travelling trolley hoist for loads from 500 to 20,000 kg Especially designed for use in areas where optimal use of short headroom is essential. Specifications of the VHR plus the following features : HPR CHDD for overhead VHR manual chain block Controlled via handwheel and chain Easy to adjust for different flange widths up to 305mm Trolley body made of high-resistance steel Side plates finished with RAL 7021 dark gray coating, 70 µ thick Steel rollers machined for smooth movement Rollers compatible with all types of I and H beams Wheel ball bearings are moisture-tight and maintenance free Galvanized hand chain Fall-prevention brackets and rubber stops Loads up to 20 tons Serial number inscribed on chassis Ex version with ATEX Marking Stainless steel lift and hand chains
