Single-cylinder roller compactor SD115B
for soil

single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
single-cylinder roller compactor
Add to favorites
Compare this product


Characteristics

Type
single-cylinder
Options
for soil
Operating weight

11,743 kg
(25,888.9 lb)

Engine power

110 kW
(149.56 hp)

Description

The new SD115B soil compactor from Volvo is packed with advanced technology – the drum is configured with ease while the engine controls itself to provide maximum versatility and performance. Step up to the Volvo designed cab and experience industry-leading low noise levels, ultimate comfort and a productive working environment. Operating weight (with ROPS, fully ballasted) - 25,614 lbs Operating weight (with ROPS, inc. Cab & inside scraper) - 25,865 lbs Centrifugal force - 46,800/58,050 lbf Vibration frequency - 1,850/2,025 v/min Optional 5x frequency (High Amplitude) - 1,400/2,025 v/min Gradeability - 65 % Rated engine power - 147.5 hp Amplitude - 0.076/0.051 in Drum width - 84 in Articulation angle - +/-35 degree Oscillation angle - +/-12 degree
