New Construction
Flush with the wall.
For low voltage (POE) only - line voltage connector is blocked
For 1/2" drywall. To install in 5/8" use a shim pack 10-01-067.
The adapter is supplied unpainted (To be painted after installation as part of the wall).
With speaker/mic grills.
For concrete installation use concrete adapter 100-1-791
Dimensions (W/H/D): 320mm (12.6")/ 255mm (10.04")/ 44mm (1.73”)
Power Supply: None (manual adapter).
