LED track light BOX 1.0
squarealuminumhome

LED track light
LED track light
LED track light
LED track light
LED track light
LED track light
LED track light
Add to favorites
Compare this product


Characteristics

Light source
LED
Diffuser shape
square
Material
aluminum
Market
commercial, home
Protection class
IP20
Dimmable
dimmable, not dimmable
Number of bulbs
single, multiple
Color
black, white, gold-colored, brown
Power

7 W

Luminous flux

440 lm, 470 lm

Color temperature

2,700 K, 3,000 K

Color rendering index (CRI)

90 unit

Height

82 mm
(3 in)

Length

70 mm
(3 in)

Width

70 mm
(3 in)

Description

48V track downlight made from die-cast aluminium; square shape; for surface and suspended tracks; adapter in Black Matt; surface housing with COB (Chip on Board) technology for maximum efficiency; non dim; light colour 2700 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; CRI (Colour Rendering Index) ≥ 90; 48 V; degree of protection IP20; PC3; UGR ≤ 13; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 1500 cd/m²; light source replaceable by an authorized professional; control gear replaceable by an authorized professional; General: Ceiling, Track, Black Matt, Adapter Black Matt, RAL 9005, Housing + Inner Reflector Black Matt + Champagne, IP20, Interior, 440 lm, CIE flux code: 98 100 100 100 100 LED: 2700 K, initial MacAdam ≤ 2 SDCM Optical: Medium, beam angle 25° Electrical: non dim, 48 V, 7.0 W, inset 7.0 W, PC3 Physical: 0.2 kg, 171 (adapter) mm, incl. Strex 48 V track adapter
