Contemporary ceiling light GRIDrectangularacrylicmetal
Add to favorites
Compare this product
Characteristics
- Style
- contemporary
- Shape
- rectangular
- Material
- metal, sheet metal, perforated metal, acrylic, opal
- Light source
- LED
- Other characteristics
- dimmable
- Market
- home, commercial
- Color
- golden, silver-colored, transparent, orange, yellow
- Protection class
- IP20
- Number of lights
- single
- Power
Max.: 28 W
Min.: 28 W
- Luminous flux
Max.: 2,210 lm
Min.: 2,210 lm
- Color temperature
Max.: 4,000 K
Min.: 3,000 K
- Color rendering index (CRI)
Max.: 100 unit
Min.: 80 unit
- Height
96 mm
(4 in)- Length
1,250 mm
(49 in)
Description
Finish
Body with squared metal holes or expanded metal. The surface has a raw finish with visible weldings through the transparent varnish. Opal acrylic diffuser available as accessory. Reflector available as accessory.
LED info
System power 28W. Luminaire luminous flux 2210 LM (see product specification). CCT 3000K (4000K on request). SDCM 3. CRI >80.
Installation
Surface-mounted ceiling installation.
Connection
Terminal block 5x4mm2.
Classification
IP20.
Design
Front Design 2012.
Standard colours
Clear lacquered metal and transparent gold. Other colours on request.
Product specification
The Grid series is produced from industry-standard sheet metal with different hole formations. Three patterns and two perforation types in the standard colours clear lacquered metal and transparent gold. Example article numbers and variants are provided below. XX codes indicate colour; HFF indicates dimmable variants.
W - MODEL - ART.
LED 2210LM/28W - Square holes - 8138-1-XX
LED 2210LM/28W - Square holes - 8138-1-XXHFF
LED 2210LM/28W - Expanded metal - 8139-1-XX
LED 2210LM/28W - Expanded metal - 8139-1-XXHFF
XX = -14 Yellow, -41 Orange, -76 Metal, -77 Gold.
HFF = Dimmable with DALI, DSI, SwitchDim.
Accessories
Reflector LED - ART. 98126-1-82
Technical specifications
Body with squared metal holes or expanded metal. The surface has a raw finish with visible weldings through the transparent varnish. Opal acrylic diffuser available as accessory. Reflector available as accessory.
LED info
System power 28W. Luminaire luminous flux 2210 LM (see product specification). CCT 3000K (4000K on request). SDCM 3. CRI >80.
Installation
Surface-mounted ceiling installation.
Connection
Terminal block 5x4mm2.
Classification
IP20.
Design
Front Design 2012.
Standard colours
Clear lacquered metal and transparent gold. Other colours on request.
Product specification
The Grid series is produced from industry-standard sheet metal with different hole formations. Three patterns and two perforation types in the standard colours clear lacquered metal and transparent gold. Example article numbers and variants are provided below. XX codes indicate colour; HFF indicates dimmable variants.
W - MODEL - ART.
LED 2210LM/28W - Square holes - 8138-1-XX
LED 2210LM/28W - Square holes - 8138-1-XXHFF
LED 2210LM/28W - Expanded metal - 8139-1-XX
LED 2210LM/28W - Expanded metal - 8139-1-XXHFF
XX = -14 Yellow, -41 Orange, -76 Metal, -77 Gold.
HFF = Dimmable with DALI, DSI, SwitchDim.
Accessories
Reflector LED - ART. 98126-1-82
Technical specifications
- Series / Model: Grid
- Finish: Body with squared metal holes or expanded metal; raw finish with visible weldings through transparent varnish
- Accessories: Opal acrylic diffuser available; reflector available (LED reflector ART. 98126-1-82)
- System power: 28W
- Luminaire luminous flux: 2210 LM
- CCT: 3000K (4000K on request)
- SDCM: 3
- CRI: >80
- Installation: Surface-mounted ceiling
- Connection: Terminal block 5x4mm2
- Classification: IP20
- Design: Front Design 2012
- Standard colours: Clear lacquered metal, transparent gold; other colours on request
- Article numbers (examples): 8138-1-XX, 8138-1-XXHFF, 8139-1-XX, 8139-1-XXHFF
- Dimming options: HFF variants - DALI, DSI, SwitchDim
