DESCRIPTION
Plan version represents, with its right shaped edges, the perfect solution for wide spaces, optimizing the time of laying, obtaining a final effect of simplicity and aesthetic harmony.
FEATURES
- Right edges
- Smooth false ceiling
- Available in prepainted and powder coated version
- Wide choice of perimeter solutions
- Total accessibility to the interspace
- Easy laying
|
|
DESCRIPTION
The metal Modular panel in flat version with module 900x900, purposely studied for the realization of false ceilings for wide areas, consents a decorative continuity of environments, warranting solutions more sought.
|
|
GemaGrid
GemaGrid is designed as a two-component system and comprises primary and secondary profiles. The primary profile (U-profile) is system-independent and a permanent component of the suspension system for every Armstrong metal ceiling. This means that the same profile can be used for every ceiling system offered by Armstrong. The secondary profile is then matched to the respective ceiling system being used. Together with the cross-shaped grid of permanently-linked primary profiles, they form the GemaGrid.
|
|
Classic
Armstrong offers the Classic suspension system as an alternative to the GemaGrid. This system, which is reduced to a minimum number of components, also has a 2-tiered structure. Bolted together into a cross-shaped grid, the cost-effective Classic is extremely sturdy and functional.
|
|
|
|
|
|
As the most widely used acoustical suspension system available, the DONN® DX®/DXL™ Ceiling Suspension System offers appropriate load-carrying capacities for acoustical panels, light fixtures and air distribution elements. Its components can be used in both general and fire-rated applications; its galvanized steel body inhibits rust.
Donn DX/DXL High Recycled Content (HRC) is available as part of the standard offering with a recycled content up to 58% and post-consumer recycled content up to 51%.
Patented QUICK-RELEASE™ cross tees are easy to remove without tools, decreasing renovation costs. Override-ends resist twisting and give a professionally finished look without exposed steel edges.
Locking tee ends provide pull-out tension values in excess of 200 lbs. Main tees are punched with cross tee holes and hanger wire holes at 6" o.c. with convenience holes at 2" o.c., providing maximum installation flexibility. Note: The DONN® DX®/DXL™ Ceiling Suspension System includes a DX422 cross tee that is not fire-rated. Using it results in a system that is not fire-rated.
The system features more than 80 UL designs (up to 3 hours), and it meets or exceeds all national code requirements, including seismic. An extensive color selection coordinates with USG ceiling panels.
Lifetime limited warranty when used with USG ceiling panels.
|
|
Model 8CPM - 625 x 625 din
Description The MICRO 8CPM heavy exposed system, is constituited by a heavy main runner and cross tees of mm. 1250 and mm. 625 hook system, with a dimension of all the system of mm. 15x38
|
|
Model 8PFH FLATLINE
Description SISTEMA 8PFH Lowered Flatline consist of Bandraster profiles as load bearing for suspended ceiling.
It is designed to be fitted up in the Crossed grid, by means of rigid hangers which allow the successives fittings of underlying movable partitios.
It can be employed in the production of noise insulating suspended ceilings. In fact, the visible flat side of the profiles is lowered from the laying edge of the panels and is box-shaped in order to contain strips of noise insulating.
|
|
|
SISTEMA 8PFL FLATLINE consist of Banraster as load bearning for suspended ceiling. It is designed to be fitted up parallel or in the cross grid, by means of rigid hangers which allow successives fitting of underlying movable partitions.
|
|
Model 8CPA - 600 x 600 met
Description The 8CPA standard exposed system is constitued by the universal heavy main runner and by light cross tees of mm. 1200 and mm. 600 with an hook system both with a dimension of 24x38
|
|
|
|
|
|
Rectangular (R) or square (Q) galvanised steel panels, thickness mm. 0,6.
Rectangular panel size: from mm 300x600 to mm. 600x1500, standard size mm. 300x1200 - mm. 600x1200.
Square panel size: from mm 300x300 to mm. 750x750, standard size mm. 600x600.
Hidden structure formed by main slotted profile and clip-type secondary profile.
Powder painting 70-80 microns.
Standard col. Ral 9010.
Minimum air space overall dimensions: mm. 100.
Ready to deliver for standard models.
It can be used in the most varied configurations and enviromental dimensions.
Simple and fast fitting of the panels.
Full inspection possibility of the hollow space by lid-release of each single panel. The inspection is made easier by the panel sliding and the clip profile.
Sound-proofing:
horizontal, by the insertion of soundproof panels on the whole surface of the false ceiling.
Vertical: by inserting plaster/paper sound-proof baffles at the walls.
Acoustic absorption:
different holes (see table) are available to the purpose, making the false ceiling soundproof together with soundproofing materials: specially suitable is the black Soundtex "paper tissue" film that dramatically reduces reverberation time and noise levels in general (see acoustic certifications).
|
|
|
For ceilings in school corridors and other environments where there is some risk of mechanical impact. Ecophon Super G Dp XL has a semi-concealed grid system, with the Dp edge securing the tiles to the grid. The tiles are demountable.
|
|
|
For applications requiring a dark ceiling having low light reflection and a concealed grid, but where individual tiles must be demountable. Ecophon Sombra Ds is installed in a suspended grid system, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are easily demountable
|
|
Economical optimization as only the required amount of wood is used
Technical flexibility room is available for cables or pipes within the slab
Lightness useful for poor-quality footings or floating buildings
Architectural personalization of the interior ceiling
|
|
|
|
