Aluminium louvre wall
System 757C
MLL-louvre wall aluminum with a free ventilation cross-section of 54%. Fixed version. The mounting at a facade done by the supporting pillar. The slats are fixed to the MLL-Clip system and later, for example for repair work on the facade or similar removable again.
Heavy Series: C-slat
Fin spacing: 100 mm
Assembly: Slat 050C on supporting pillar 007, supporting pillar 007 with retainer 15.2, supporting pillar distance 1200 mm
Surface: E6 / EV1 anodised, E6 / C31-35 shades, RAL to choose / raw
Special colors on request
All profiles are made of Al MG Si 0,5.
The MLL-facade system 757C is one of our heavy series. The slat is C-shaped with a supporting pillar. The supporting pillar is ideal for quick assembly on the substructure.
Application:
Ventilation element large slatted look. Wherever an enclosed, harmonious and discreet wall optics is to be achieved. The selection of the slats size and shape depends on the desired benefits and the overall look of the building.
Our MLL facade systems are air-permeable louvre walls. Between masonry and slat arises an air circulation, thus there is no accumulation of heat accumulation or moisture. The MLL-slat walls protect against outside weather conditions. They have many design possibilities with the slats at the building.
Note:
Additional product information and technical drawings can be found on the following link on our website.
