CAD software VENTILATION

architecturefor hydraulic and thermal installations3D

This Building module makes it easy for you to design and evaluate entire ventilation systems for square ducts, round pipes or oval pipes. The high level of functionality of the 3D design tool incorporating predimensioning using the duct slider is impressive. It is the ideal tool for model-based design of highly complex ventilation systems. When designing with Promat ducts and insulated ducts you can fall back on corresponding visualization variants. Components are positioned automatically by selection of the start and end point. Highlights: Define the volume flow using a room stamp Design and construction assistants Bill of equipment of all components, pipelines and insulation Ventilation system configurator Basic molded part variants (T-pieces, rivet board, straights, bends, separators) Integrated interface to Klimax Integrated Kancalc from mh-software to calculate pressure loss
