The switch actuator uses potential free contacts to switch 2 independent electrical loads via ABB i-bus® KNX. The device has integrated energy functions. This includes independent load current measurement in each output and easy to use calculation of power and energy consumption for each output or groups of outputs. Via an integrated load shedding object an integration in a load control system can be easily realized. The device features a manual operation and displaying of the switching state of the outputs. The 16/20 A, 16 A-AC3 (C-load) device is especially suited for loads with high surge currents e.g. LED or fluorescent lighting (AX) acc. EN60669.
Dimensions
Product Net Depth / Length:63.5 mm
Product Net Height:90 mm
Product Net Width:210 mm
Product Net Weight:0.845 kg
Technical
Compatible Bus Systems:KNX (TP)
Degree of Protection:IP20
Mounting Type:DIN-rail
Width in Number of Modular Spacings:12
