Door hinge NEO M6 SELFCLOSE

with self-closing systemconcealedblack

Product description
The invisible NEO M6 Selfclose is the self-closing variant of the NEO M6 concealed hinge. It pairs a minimal, flush appearance with an integrated automatic closing mechanism built into the door leaf, providing discreet functionality without visible hardware.

What makes the NEO M6 Selfclose so unique?

• Self-closing variant of the NEO M6 — designed to work together with standard NEO M6 hinges; recommended as the second hinge from the top for optimal operation.
• High-capacity self-closing hinge for doors up to 60 kg — a single NEO M6 Selfclose hinge reliably closes doors up to 60 kg.
• Automatic closing with accelerated final movement — activates from an opening angle below 135° and provides an accelerated final stroke to ensure secure closure.
• Easy 3D adjustment — full three-dimensional adjustment without removing the door; closing speed is adjustable for balanced motion.
• Full freedom with 180° opening — allows wide passage and flexible interior layouts.
• Suitable for any handing and interiors — available for left- and right-hinged doors and in finishes black, white, matt chrome and bronze.
• Ideal for Invisidoor Arched installations — solution where traditional door closers cannot be fitted, enabling automatic closing without compromising design.

Technical specifications

• Model: NEO M6 Selfclose (self-closing variant of the invisible NEO M6 hinge).
• Installation: fitted as the second hinge from the top; compatible with standard NEO M6 hinges.
• Maximum door weight per single Selfclose hinge: up to 60 kg.
• Automatic closing activation angle: from less than 135°.
• Final movement: accelerated final stroke for secure closure.
• Adjustment: full 3D adjustment without door removal; adjustable closing speed.
• Opening angle: up to 180°.
• Handing: suitable for left- and right-hinged doors.
• Available finishes: black, white, matt chrome and bronze.
• Compatibility: suitable for Invisidoor Arched where traditional door closers cannot be used.
