Door hinge TYOconcealeduniversalblack
Add to favorites
Compare this product
Characteristics
- Product applications
- door
- Technical characteristics
- concealed, universal
- Finish
- black, white, gray
- Opening angle
- 180°
- Height
110 mm
(4.3 in)- Width
30 mm
(1.2 in)- Thickness
38 mm
(1.5 in)- Maximum load
Max.: 95 kg
(209.4 lb)Min.: 60 kg
(132.3 lb)
Description
The Invisible TYO is an architectural detail that enables simplicity in slim door frames. The hinge disappears completely from view, allowing the door surface and the space to retain their clean, minimalist lines.
Developed for an installation depth of just 21 mm, TYO fits effortlessly into fine wooden frames. It remains fully 3D adjustable, allowing the door to be aligned exactly to the desired level of precision.
All screws are discreetly hidden behind cover plates and the 180° opening angle ensures maximum freedom of use. TYO is suitable for both left and right-hinged doors.
The Invisible TYO combines compact design with technical finesse, ideal for architects who want to achieve a sleek, uninterrupted door appearance in limited installation situations.
Developed for an installation depth of just 21 mm, TYO fits effortlessly into fine wooden frames. It remains fully 3D adjustable, allowing the door to be aligned exactly to the desired level of precision.
All screws are discreetly hidden behind cover plates and the 180° opening angle ensures maximum freedom of use. TYO is suitable for both left and right-hinged doors.
The Invisible TYO combines compact design with technical finesse, ideal for architects who want to achieve a sleek, uninterrupted door appearance in limited installation situations.
