Motion detector DS9370/DS9371 SERIES

intrusionceiling-mountedcommercial

Up to 6.1 m (20 ft) mounting height Fully adjustable optics for coverage integrity and customization Hinged chassis and base plate for easy installation High efficiency LED and light pipe system for easy walk testing First Step processing, or FSP Each DS9370 Series TriTech PIR/Microwave Doppler radar Motion Detector model is panoramic and uses several patented processing techniques to provide excellent catch performance with freedom from false alarms. Each model can be mounted on ceilings as high as 6.1 m (20 ft). With three separate PIR sections that are fully adjustable, the DS9370 Series provides coverage integrity at all mounting heights, plus the ability to customize the coverage for specific areas. Uses passive infrared and microwave Doppler radar technologies to provide an alarm condition when both fields of protection are simultaneously activated. Alarm signals must meet the signaling requirements of both technologies to activate an alarm. FSP allows virtually instant response to human targets without sacrificing false alarm immunity to other sources. By adjusting its sensitivity based upon signal amplitude, polarity, slope and timing, FSP eliminates the need for the installer to select the sensitivity level for the application. Each sensor is processed individually and both must agree there is an alarm before the alarm relay is activated. Microwave Noise Adaptive Processing Adaptive processing adjusts to background disturbances. This helps to reduce false alarms while maintaining catch performance.
