Urban lamp post IFLAT
contemporarycast aluminumstainless steel

Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 2
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 3
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 4
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 5
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 6
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 7
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 8
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 9
Urban lamp post - IFLAT - BSI LIGHTING TECHNOLOGIES INC. - contemporary / cast aluminum / stainless steel - image - 10
Add to favorites
Compare this product

Characteristics

Type
urban
Style
contemporary
Material
cast aluminum, stainless steel, with tempered glass diffuser
Light source
LED
Number of lights
multiple
Shape
rectangular
Support type
straight
Protection class
IP66
Color
black, gray, silver-colored, brown
Height

Max.: 8 m
(26'02" )

Min.: 4 m
(13'01" )

Length

Max.: 580 mm
(23 in)

Min.: 400 mm
(16 in)

Width

50 mm, 60 mm
(2 in, 2 in)

Color temperature

3,000 K, 4,000 K

Color rendering index (CRI)

80 unit, 90 unit

Luminous flux

Max.: 29,252 lm

Min.: 7,290 lm

Power

Max.: 206 W

Min.: 54 W

Description

iFlat is a functional LED lighting solution for exterior lighting applications. By using the same lighting platform and incorporating a new and unique BSISQ® LED Module; the luminaire achieves the required illumination levels and distribution in pedestrian, site, roadway environments. iFlat is a modular urban lighting system with the perfect combination of design and innovation. The different installation configurations and the wide range of optics ensure lighting for urban environments that guarantees energy savings and respect for the ecosystem. The compact design and reduced size of the luminaire allow its addition with balance and discretion to any urban context, from big cities to small district towns. Architectural LED lighting luminaire range inspires architects, designers and system integrators with its exceptional quality, a variety of beam angles and remarkable creativity. Designed to last in extremely harsh environments. Innovative and Effective : iFlat has been designed to offer better lighting performances, simplify the installation and the maintenance of the lighting devices and promote the maximum energy-saving. It is the ideal solution to all types of urban and interurban road lighting, round-about, outdoor areas and parking lots, both for new and existing installations. The luminaire with stylized appearance and with improvements in installation, maintenance and service life offers a wide variety of light distributions that ensure effective values, visual comfort and light output for pedestrian areas and streets without light pollution.
