Urban lamp post IBRIZA

contemporarycast aluminumstainless steel

Modern, discreet and versatile post top LED lantern integrates into the cityscape and residential areas with the asymmetrical beam allowing optimum light distribution. BSISQ® LED Module integrated. Designed to last in extremely harsh environments. LED Type - High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant. Nominal Voltage - 220V-240V AC, 50/60Hz Color Rendering Index - CRI> 80 standard and CRI>90 on request. Optics - Rotationally symmetrical 30°/ 60° / 90° or asymmetrical M3 street optics. Materials - Corrosion resistant double layer polyester powder coated paint finish die cast aluminium housing with stainless steel screws (A4 grade) and silicone gaskets. Power unit is built in. Available in anthracite gray as a standard finish or any desired RAL colour. BSISQ® LED Module. Optional Coating - Marine grade. Diffuser - Thermal-shock resistant tempered glass. LED Specification. - L90B50 > 100000 hours life time. Energy Effciency Class (EEC) - A++ Operating Temperature - -40°C / +55°C Power Factor - >0.95 Control Systems - DALI Interface. Protection Class - IP66 Impact Resistance - IK08 Insulation Class - Class I Conformity - Complies with European Standards EN 60598 and CE certified.
