Specifications
glassPIVOT > FRAMELESS (PIVDR-XF)
Offset pivot-mounted glass panel.
Hydraulic mechanism allows for controlled self-closing movement.
VALUE-ADDED BENEFITS
Easy installation: pre-assembled door panel
Efficient operation: simple hardware design
Minimal visible hardware
System durability and long-term integrity
Turnkey integrated project services
FACILITY DESIGN APPLICATIONS
Space division between offices, conference rooms or flex-space, bathrooms.
CONFIGURATIONS
Single and double leaf.
FUNCTION
Swinging pivot door.
GLASS TYPES
Tempered monolithic. Tempered laminated.
GLASS FINISHES
Refer to Finish Chart CARVART laminated transparent glass design options available: 01 Core, 02 Color, 03 Pattern, 04 Metallic, 05 Textile, 08 Gradient and 10 Covert.
SURFACES
Smooth glass. Etched glass.
GLASS THICKNESS
Refer to local code and structural requirements Accommodates 3/8" - 9/16" nominal.
HARDWARE DIMENSIONS
Aluminum patch: XX
HARDWARE MATERIALS/FINISHES
Refer to Finish Chart Satin anodized aluminum. Brushed "stainless" aluminum.
WIDTHS — OVERALL MINIMUM/ MAXIMUM RANGE (inches):
Glass panels: Minimum 28". Maximum 46".
HEIGHTS — OVERALL MINIMUM/ MAXIMUM RANGE (inches):
Glass panels: Minimum 60" height. Maximum 108" height above finished floors.
MOUNTING FASTENERS
Final anchoring decision is client-directed or based on client structural consultant. Mounting fasteners and anchors to be supplied by others. CARVART advisory and coordination available.
WEIGHT & STRUCTURAL LOADS
Consult local engineer for structural codes and requirements Pivots for individual panels rated up to 220 lbs. Linear per foot weights based on final glass type.
