Polyester expansion joint SMN SERIES

metalcoatingfloor

Our range of metal wall covers for interior applications have been designed as matching counterparts to our floor expansion joint covers. Simple and quick to install we offer surface mounted options as well as recess mounted options for a flush finish. Covers are supplied clear anodised as standard, but can be powder coated to match the adjacent wall finish. Surface mounted aluminium wall joint covers, which can also be used as ceiling covers where the construction permits. With no exposed fasteners, this cover stands out for being tamper-proof and low maintenance. Easy to install, these covers are often used for masonry applications where flush covers cannot be mounted into the wall structure. This sleek and stylish aluminium wall cover is supplied clear anodised but can be painted to match surrounding walls, or ordered with a polyester powder coating. Joint Width: up to 50mm Horizontal: up to +60/-40mm Vertical: up to ±4mm Lateral: up to ±5mm Aluminium sections: covers are supplied in a natural anodised finish as standard, or can be polyester powder coated (subject to minimum quantity). Continuous aluminium anchor clip is mill finished. Fixings (by others) to suit substrate at 450mm centres. Note: Anchor clip sections are not supplied pre-drilled. Aluminium sections: 3m
