Plastic ventilation grill RS-5605
aluminiumsquareexterior

Plastic ventilation grill - RS-5605 - CS Construction Specialties - aluminium / square / exterior
Plastic ventilation grill - RS-5605 - CS Construction Specialties - aluminium / square / exterior
Add to favorites
Compare this product

Characteristics

Material
plastic, aluminium
Shape
square
Interior/exterior use
exterior, interior
Market
commercial, home, industrial
Applications
for facade
Color
gray
Other characteristics
for air supply and exhaust, cover, burglar-resistant
Width

1,000 mm
(39 in)

Length

1,000 mm
(39 in)

Description

High performing louvres with vertical blades and visible mullions, offering excellent protection against wind-driven rain penetration and good airflow. KEY FEATURES Blade Orientation: Vertical Mullion Type: Visible Louvre Depth: 129mm Blade Pitch: 51mm Weight: 25kg/m2 based on a 2m x 2m module size PERFORMANCE SUMMARY Rain Penetration Class: A up to 3.5m/s Airflow Class: 3 (entry & discharge) Airflow Coefficient Ce (entry): 0.287 Airflow Coefficient Cd (discharge): 0.251 K factor (entry / discharge): 12.140 / 15.873 OPTIONAL EXTRAS Glazing frame Head / cill / jamb cover plates Blanking panels (single skin or insulated) Bird / vermin guards, insect mesh Louvred doors Dampers ADDITIONAL SECURITY OPTIONS Burglar Resistance Class: RC2 (tested to EN 1627-1630) Blast Resistant Option: Can withstand up to 12.6psi blast pressure at an impulse of 77.8 psi-msec
