Positive refrigerated cabinet GAHPT PASS-THRU

Cabinets are designed to maintain temperatures between 120ºF and 200ºF. Heating elements are located behind the vertical ducts. The design of the heater, which is full length of the vertical duct, allows for optimal air flow and energy efficiency. Fan motor is mounted outside of the heated compartment. System is controlled using an electronic temperature control. Units are completely insulated with high density foamed in place environmentally friendly, Kyoto Protocol Compliant, Non ODP (Ozone Depletion Potential), Non GWP (Global Warming Potential) polyurethane. W x D x H - 271/2" x 321/2" x 793/8" 27.4cm x 32.44cm x 79.38cm Weight - 361 lb 163.7 kg Power Output - 6.00 Amps Power Input Type - Electric Primary Power Input - 208-240 V x 60 Hz x 1 PH 3 shelves per section 10’ cord and plug attached 208V / 60C / 1 P Standard 40 watt incandescent light 5” locking casters shipped loose for field installation Accommodates full size sheet pans Chrome standard Digital exterior temperature display with high/low temp visual alarms Door locks easyTouch Control with remote monitoring capability Energy efficient door gasket removable without tools Field rehingable doors full height doors only Removable side louver Smart door hinge that auto closes up to 90˚ and stays open past 90˚ Stainless steel exterior front, sides & interior Stainless steel pilaster with shelf clips Three year parts and labor warranty
