Facade renovation covering ECOREFLEX

for ceilingroof

Product overview:
Water-based, ultra-reflective, self-cleaning photocatalytic resin protective coating. Ecoreflex initiates a photocatalytic process that decomposes pollutants and reduces local pollution. It reflects solar radiation, lowers substrate temperature and helps reduce summer air-conditioning energy needs. Ready to use; suitable for horizontal, vertical and sloped surfaces with good adhesion even on slightly bituminous or slated substrates.

Key properties:

• Photocatalytic, self-cleaning action
• Significant smog abatement capability (isopropanol conversion: 80% after 24 h under test conditions)
• Contributes to reduced energy demand for summer air conditioning
• Reduces urban heat island effect
• Compatible as a finish for waterproofing systems based on synthetic resins
• High solar reflectance (82%)
• High thermal emissivity (E = 90%) and SRI = 103%
• High elasticity across temperature range
• Good re-waterproofing capability
• Easy and quick to apply; solvent free

Yield and packaging:
– Yield: 1.00 kg/m² = 0.204 lb/ft²
– Packaging: 5 kg plastic bucket; 20 kg plastic bucket

Drying time and application:
– Drying time: approx. 5 h (value referred to +23°C / +73°F and 50% RH)

Application methods:

• Brush
• Roll
• Airless spray

Detailed characteristics and performance data:
Appearance: Liquid
Components: One-component formulation
Isopropanol conversion (smog simulant) with Vitalus-Osram broad spectrum lamps (300 W): 80% after 24 h irradiation
Smoke test (yellowing 15 days + 3 h UVB): noticeable whitening (self-cleaning)
Reflection (reflectance): 82%
Thermal emission (E): 90%
Solar Reflectance Index (SRI): 103%
Weathering test: 1680 h (equivalent to >10 years)
Resistance to 50 freeze–thaw cycles (-15°C/+15°C): unchanged
Bending strength (flexibility): 12 mm – good
Break elongation: 327% (initial)
Adhesion: > 7.0 MPa on slightly worn bituminous membrane; 4.3 MPa on slated sheath; 2.5 MPa on slate; 1.7 MPa on galvanized sheet; 1.5 MPa on PU panel
Elongation at break after 1680 h accelerated aging: 166%
Tensile strength after 1680 h accelerated aging: 1.12 N/mm²
Viscosity (Brookfield DV-E s04, 6 rpm; T = 20 °C, 75% R.H.): 24000 mPa·s

Technical specifications:

• Yield: 1.00 kg/m² = 0.204 lb/ft²
• Packaging: 5 kg and 20 kg plastic buckets
• Drying time: approx. 5 h at +23°C and 50% RH
• Application methods: brush, roll, airless
• Appearance: liquid; one-component
• Photocatalytic isopropanol conversion: 80% after 24 h (test conditions)
• Reflectance: 82%; Thermal emission (E): 90%; SRI: 103%
• Weathering resistance: 1680 h (~>10 years)
• Freeze–thaw resistance: unchanged after 50 cycles (-15°C/+15°C)
• Elongation at break: 327% (initial), 166% after accelerated aging
• Tensile strength after aging: 1.12 N/mm²
• Adhesion on various substrates: bituminous membrane >7.0 MPa; slated sheath 4.3 MPa; slate 2.5 MPa; galvanized sheet 1.7 MPa; PU panel 1.5 MPa
• Viscosity (Brookfield): 24000 mPa·s (conditions specified)
