Access ladder API INDIVIDUAL DOUBLE WALL ACCESS

aluminum

KEY FEATURES Secured workstation for concreting double walls and prefabs. Working height up to 5.11 m. Safety 1 6 height setups. Sturdy aluminium structure. Light: 17 kg only. Fast deployment. Height is locked with captive pins. Comfortable access to the floor. Protection: handrails. 2 hooks of different sizes included. Hooks can be disassembled and are interchangeable. Can be hoisted using two dedicated anchor points. Overall size has been optimized for transport. SPECIFICATIONS Aluminium. Decree 2004-924. Max work height: 5.11 m. Max hooking height: 4.04 m. Platform height adjustable between 1.93 and 3.11 m. Height is locked with captive pins. Adjustable hooks over 700 mm. 2 hooks included: 75 and 200 mm. Non-slip rungs 80 mm. Platform 0.45 x 0.50 m – integrated alu. toe board. Load capacity: 150 kg. Folded dim.: H. 2.90 m x W. 0.58 m x THK 0.79 m. Weight: 19.5 kg. Delivered assembled. Assembly type: welded. Made in France.
