HC812-300 MONO
Ideal for single swing gates up to 2,5m/8ft wing lenght
Ducati's classic vintage design gate opener featuring:
This classic DUCATI "vintage" design gate operator features several advanced options combined with telescopic actuator for greater strength and less mechanical stress of the system.
1x HC312 - 300mm stroke 12V telescopic electromecanic irreversible actuator supplied with 1 m outdoor use cable H05RN-F 2 x 1mmq
set of actuator's fixing brackets
1x 7855Rol - large control box with electronic board CTH42, toroidal transformer, integrated radio receiver
2x 6203Roll - 2 buttons 433,92 MHz rolling coded radio transmitters
1x HC7500 - blinking light 12V
1x SW5000 - key switch
1x key for manual emergency release
1x instruction manual
DUCO SAFE
obstacle detection safety system guarantees maximal safety of use to your family
SELF LOCK TECHNOLOGY
The self-locking properties of the spindle increase the protection against a dangerous and unauthorised “pressing” of the gate and the otherwise necessary e-locks for the final positions can be omitted. A massive 20 mm diameter three principle steel spindle made of PR80 steel ensures long and reliable operation
. Ideal for a safe, quick and easy installation: the system works in DC current and is
electrocution risk-free.
. Possibility of connecting an external timed courtesy light (example: garden light)
. 2 working modes: "STEP by STEP" ( push to open & push to close) or Automatic close with
adjustable time (you can vary the pause time from 1 to 100 seconds)
. Control unit with integrated battery housing compartment: can fit any 12v battery up to
maximal dimension : 9cm x 15cm x 9,5cm h
