Temperature controller UTR 20

Moisture-proof controller, surface mounting -40...20°C, AC 230V, 1 changeover contact, potential-free, 16A, IP65 Contact - Heating and cooling (change over, voltage-free) Voltage - AC 230 V 48 … 62 Hz Switching current - AC 16A at cos ϕ = 1; 4 A at cos ϕ = 0,6 Temperature range - -40 … 20°C Measurements - 122 x 120 x 56 mm Universal temperature controller with remote sensor (not included, must be ordered separately) for wall mounting is particularly suitable for use outdoors or in damp rooms. The control unit can be used either as an outdoor or indoor scale. The delivery condition is with outdoor scale. Control lamp, controller requests heat and sensor break. Adjustable switching temperature difference from +/- 0.5K to +/- 5K. Temperature setback possible via external timer. degree of protection IP 65, probe extendable up to 100 m, with control lamps "relay on" and "probe break", temperature reduction approx. 5 K (control via external timer)
