Mechanical thermostat RTR-S 6202-6

manualfor heatingwall-mounted

Room controller, 5...60°C, UC 24V, 1 changeover contact, 1/1 A Contact - Heating Voltage - AC 230 V 50 Hz Switching current - AC 10 mA…5A at cosϕ = 1; 10 mA…2 A at cosϕ = 0,6 Temperature range - 5 … 30°C Measurements - 76 x 76 x 18,5 mm Room controller, slim and elegant with very low installation height of only 18.5 mm for wall mounting. Suitable for controlling central, hot water floor, electric, night storage heaters, etc. Proven bimetal technology, a captive screw with threaded insert for fastening the housing cover. Easy mounting thanks to quadruple fixing. The terminals are designed for wires up to 2.5qmm. extra flat, 18.5 mm, with temperature reduction, control via external timer, 1 mains switch, 1 pilot lamp: heating
