Pool heat exchanger ESCALADE

The Escalade is a fully welded titanium spiral tube heat exchanger that has a high-pressure tolerance and is the perfect solution for most demanding applications. Features & Benefits • Three models ranging from 30-kW to 75-kW • High efficiency, titanium spiral coil is fully immersed in the secondary chamber • Coiled grade 1 titanium primary casing • Salt and sea water compatible • 30 bar (primary) and 5 bar (secondary) pressure tolerance • Low pressure drop • With optional Smart Touchscreen Controller and Booster Pump • Temperature and flow sensor port • Floor or wall mountable Flow Tube : Primary Circuit: Coiled grade 1 titanium Secondary Circuit: Grade 1 titanium Water Connections : Primary Circuit: 1" BSP male fittings Secondary Circuit: 1.5" BSP female fittings Working Pressure : Primary Circuit: 30 bar maximum Secondary Circuit: 5 bar maximum
