LED floodlight LIGHTSCAN

commercialoutdoorsurface-mounted

Lightscan by ERCO is a range of outdoor floodlights designed for architectural accenting and powerful facade illumination where high luminous flux or limited mounting positions are required.

Key features

• Large lumen packages for very high illuminances suitable for tall buildings and distant objects.
• Precise light distributions (ERCO Spherolit lens) to direct light only where needed.
• Rotatable Oval flood: 360° rotation for optimal beam alignment to varied objects.
• Multiple construction sizes covering a wide range of lumen classes.
• Slender, weatherproof housing with options for extensive colour customization.
• Mounting accessories for tilt and rotation to suit different installation situations.
• Maintenance‑free, highly efficient optoelectronics to reduce operating costs.

Product description
Lightscan provides targeted accent and floodlighting for façades, walls and architectural elements. High luminous fluxes enable effective illumination even for high elevations or when mounting positions are restricted. A set of precise distributions ensures that light is placed exactly where required. The slim, weatherproof housing integrates discreetly into the building geometry. Available mounting accessories permit tailored installation and aiming on site. The maintenance‑free optoelectronics offer long service life and low energy consumption.

Variants / Customisation options

• High‑power LED options: 3000K CRI 97; also 2700K, 3500K, 4000K with CRI 92.
• Housing finishes: Graphit m and up to 10,000 additional colours (ERCO individual options on request).

Technical specifications (selection)

• Series / model: Lightscan
• Light source power range (projectors): approx. 2 W – 97 W
• Luminous flux range (projectors): approx. 217 lm – 12,576 lm
• Light distributions (ERCO Spherolit lens): Narrow spot, Spot, Flood, Wide flood, Extra wide flood, Oval flood, Wallwash
• Oval flood: 360° rotation for alignment
• LED colour temperatures and CRI: 3000K CRI 97; 2700K, 3500K, 4000K with CRI 92
• Optics: collimating lens made of optical polymer for high visual comfort
• Housing: corrosion‑resistant die‑cast aluminium, No‑Rinse surface treatment, double powder coating; protection glass
• Mounting: mounting plate and hinge in corrosion‑resistant cast aluminium or polymer; up to 90° tilt and 300° or 360° rotation (depending on variant)
• Control / dimming: switchable, phase dimmable + On‑board Dim, DALI, Casambi Bluetooth
• Applications: accent lighting of architectural elements, façade floodlighting, wallwashing
• Weather protection: designed for outdoor use with robust, maintenance‑free optoelectronics
