Installation
Luminaire for installation on a post with post top Ø 60 with Ø 48 mm bracket or using a nipple bracket.
Connection
Terminal block, 3x2.5 mm². A 3x1.5 mm² connection cable measuring 10 m is supplied for nipple brackets.
Design
Luminaire top of die-cast aluminium. Aluminium shades. Sections between the shades are of opal acrylic glass. Toughened protective plate glass with quick-action catches.
Optics
Asymmetric street lighting optic with lenses.
Dimming
Night reduction technology is available with additional suffix codes for this product. Scene 1 (-466 ). Scene 2 (-467 ). Scene 3 (-468 ). Learn more about Night reduction technology under Light control.
Accessories
See Accessories.
Standard Colour
Black (RAL 9005). Alu-grey (RAL 9006).
LED-information
3000 K: Ra (CRI) min. 80. MacAdam 3 SDCM. 4000 K: Ra (CRI) min. 70. MacAdam 5 SDCM.
Miscellaneous
Projected wind area 0.09 m².
