Aluminium window INNOVIEW

wood-aluminumlaminated woodcasement

Overview
The combination of laminated solid wood on the interior with aluminium cladding on the exterior creates a composite window that pairs natural wood aesthetics with an aluminium outer shell for weather resistance. Profiles are offered in three thicknesses (68 mm, 78 mm and 92 mm) to suit standard and large glazing while ensuring sash rigidity and stable operation. The interior provides a refined wooden finish; the aluminium exterior reduces external maintenance and resists rain, sun and temperature variations.

Glazing
The system accepts single-, double- and triple‑chamber insulating glazing units from 24 mm up to 64 mm thickness. Options include low‑U glazing (Ug down to 0.3 W/m²K) and acoustically laminated glass for enhanced sound insulation. The glazing range allows balancing thermal performance, acoustic criteria and safety requirements.

Design freedom and finishes
Three profile thicknesses, several wood species and a wide palette of aluminium colours enable strong customization. Large formats, multi‑pane compositions and non‑standard shapes can be combined without compromising performance. Interior wood surfaces can be finished with transparent varnishes or opaque coatings; aluminium cladding is available in multiple RAL/anodised options and in stylistic variants SOFT, MODERN and PURE.

Operation, fittings and security
Tilt‑and‑turn and turn‑only opening types are available and engineered for heavy sashes: standard fittings support sash weights up to 150 kg; tilt‑and‑turn versions up to 200 kg; turn‑only versions up to 300 kg. The windows use SIEGENIA fittings designed for thicker profiles and heavier glazing, offering multi‑point locking, perimeter compression, multidimensional adjustment and concealed‑hinge options. RC2 burglary resistance is available as an option.

Sealing and weather resistance
Windows feature a multi‑seal system (EPDM/TPE) ensuring high air and water tightness compatible with energy‑efficient building envelopes. Aluminium cladding acts as a protective outer shell that stabilises the wooden profile and reduces the need for exterior maintenance.

Acoustics and interior quality
Thick glazing units (36–64 mm) with acoustic laminates significantly reduce external noise intrusion, improving comfort in urban or noisy locations. Interior surfaces are high‑density laminated wood selected for visual quality and dimensional stability; a broad range of varnishes and coatings preserves the natural look and raises interior finishing standards.

Components and accessories
The product is supplied with premium components: abrasion‑resistant locking elements and handles, perimeter multi‑point locking, mushroom cams and options for concealed hinges. Handles and cover finishes are available in multiple finishes to match profile colours.

What distinguishes the fittings used

• RC2 burglary resistance class available as an option
• Mechanisms that adapt to sash operation with temperature and load changes
• Concealed hinges for improved aesthetics
• Multi‑point locking system maintaining even pressure around the entire perimeter

Additional notes

• Low aluminium threshold option for balcony/terrace doors to facilitate passage and reduce barrier height
• TGI low‑conductivity spacer used in glazing units to reduce thermal bridging at the glass edge
• Four‑component EPDM/TPE peripheral seal system for long‑term tightness and flexibility across temperatures

Technical specifications

• Series / model: INNOVIEW
• Manufacturer / brand: FAKRO
• Profiles: laminated wood with aluminium cladding
• Available profile thicknesses: 68 mm, 78 mm, 92 mm
• Glazing unit thickness: 24–64 mm (single, double and triple‑chamber options)
• Ug (glazing) achievable: down to 0.3 W/m²K (depending on configuration)
• Window Uw (system): reported up to 0.68 W/m²K for certain configurations
• Fittings: SIEGENIA systems; multi‑point locking; concealed hinge options; optional RC2
• Sash weight capacity: up to 150 kg (standard fittings), up to 200 kg (tilt‑and‑turn), up to 300 kg (turn‑only)
• Seals: EPDM/TPE multi‑seal system (four peripheral seals)
• Acoustic options: laminated acoustic glass, glazing up to 64 mm for enhanced sound reduction
• Exterior finish: aluminium cladding available in many RAL/anodised colours; stylistic variants SOFT, MODERN, PURE
• Interior finish: variety of wood species and varnish/opaque coatings; UV and abrasion resistant
• Threshold: low aluminium threshold available for balcony doors
• Inter‑pane spacer: TGI low‑thermal‑conductivity spacer
