Digital time switch 84 SERIES

panel-mounted

Overview
The 84 Series SMARTimer is a digital multi-function timer designed for industrial control and automation. It combines NFC smartphone programming and a local joystick interface with a wide backlit display for clear parameter setting.

Functions and features

• Two programming modes: smartphone via NFC or built-in joystick
• Wide backlit display for easy reading
• Multifunction: 25 available functions per channel
• Time units: 0.1 s, s, min, h
• Outputs: 2 changeover contacts (1 CO + 1 CO), rated 16 A

Types / Example

• Type 84.02 - SMARTimer 16A
• Type 84.02 features: 2 changeover contacts rated 16 A
• Supply voltages available: 12–24 V AC/DC and 110–240 V AC/DC (non-polarized)

Applications

• Industrial automation and machinery control
• Process timing and sequencing
• Building and HVAC control panels
• OEM control systems

Technical specifications

• Product family / series: 84 Series
• Commercial name: SMARTimer
• Multi-function timer: 25 functions per channel
• Programming: NFC with smartphone or local joystick
• Display: Wide backlit display
• Time units: 0.1 s, s, min, h
• Outputs: 2 changeover contacts (1 CO + 1 CO), 16 A
• Example type: 84.02 (SMARTimer 16A)
• Supply voltages: 12–24 V AC/DC and 110–240 V AC/DC (non-polarized)
