Stainless steel glass clamp

for railingfor glass panelsfor stair

Overview
Giotto is a high‑end glass spacer engineered for three‑axis (X–Y–Z) adjustment after glass installation. Available in multiple diameters and lengths, including a slotted‑base variant. Compatible with two glass thickness ranges for broad application flexibility. Giotto is a patented, proprietary solution.

Material and system
Manufactured in AISI 316 stainless steel. Adjustment is provided via a patented eccentric mechanism that enables precise alignment on mounted glass.

Performance and testing
Tested to withstand 2 kN/m in accordance with UNI 1010.4 SG.

Applications and availability
Designed for architectural glass fixings such as balustrades, staircases and parapets where in‑situ glass adjustment is required. Available in various diameters and lengths; slotted‑base versions available on request.

Technical specifications

• Model: Giotto
• Material: AISI 316 stainless steel
• Adjustment: patented eccentric system, 3‑axis (X–Y–Z) adjustment on mounted glass
• Compatible glass thickness: 10–12 mm and 16.76–21.52 mm
• Variants: multiple diameters and lengths; slotted‑base option available
• Load performance: tested to 2 kN/m (UNI 1010.4 SG)
• Patent: patented / exclusive product
