Gateway interface module BTIRF-02/00.2

KNX

KNX Gateway for IR includes KNX Gateway for IR,Flush mounted,2-Fold (BTIRF-02/00.2) and KNX Gateway for IR,Ceiling (BTIRC-01/00.2). Each product has 2 IR emission channels which can be set as universal IR control or Air-condition control, up to store 300 different IR codes. In addition, KNX Gateway for IR,Flush mounted also has 1 fold current detection function, which can confirm the on or off status of controlled device via current status, and avoid false triggers if On and Off are controlled by the same IR code. KNX Gateway for IR,Ceiling supports for a 360° all-round emitted Operation voltage 21-30V DC, via the KNX bus Bus current <8mA, 24V；<7mA, 30V Bus consumption <210mW Dynamic current <14mA, 24V ；<12mA, 30V IR wavelength 940nm Radius distance <3m Installation Height <4m KNX Bus connection terminal(Red/Black) Operation – 5 °C ... 45 °C Storage – 25 °C ... 55 °C Transportation – 25 °C ... 70 °C Humidity <93%, except dewing Dimension 91 × 76 × 82.25mm Weight 0.05kg
